Comprehensive Guide to CISPR 22 Radiated and Conducted Emission Test for IT Equipment Laboratory Testing Service

Standard-Related Information

CISPR 22 is an international standard that governs the radiated and conducted emission testing of information technology (IT) equipment. This standard is part of a suite of standards published by the International Electrotechnical Commission (IEC), which aims to establish common technical requirements for the design, manufacture, and operation of electrical and electronic equipment.

ISO, ASTM, EN, TSE, and Other Relevant Standards

  • ISO 17025:2005 General Requirements for the Competence of Testing and Calibration Laboratories

  • IEC 61000-3-2:2018 Electromagnetic compatibility (EMC) - Part 3-2: Limits - Limits for harmonic current emissions (equipment input current 16 A per phase)

  • EN 55022:2010 Information technology equipment -- Radio disturbance characteristics -- Limits and methods of measurement

  • TSE 16649:2017 Information Technology Equipment -- Safety Requirements

    • Standard Development Organizations

    The International Electrotechnical Commission (IEC) is the primary standard development organization responsible for CISPR 22. The IEC is a non-profit, independent organization that brings together representatives from national electrotechnical committees to develop and maintain international standards.

    Standard Evolution and Updates

    Standards evolve over time as new technologies emerge and existing ones advance. The CISPR 22 standard has undergone numerous revisions since its initial publication in 1988. The most recent edition was published in 2010, with further updates and amendments in subsequent years.

    Industry-Specific Compliance Requirements

    CISPR 22 applies to a wide range of IT equipment, including computers, telecommunication systems, and medical devices. Manufacturers must ensure that their products comply with the relevant standards for their specific industry sector.

    Standard Requirements and Needs

    The CISPR 22 standard is essential for ensuring the electromagnetic compatibility (EMC) of IT equipment. Non-compliance can result in interference with other equipment, malfunctioning, or even catastrophic failure. The consequences of not performing this test include:

  • Interference with other equipment

  • Malfunctioning or complete failure

  • Customer dissatisfaction and financial losses

  • Compliance issues with regulatory bodies

    • Industries and Sectors Requiring This Testing

    CISPR 22 applies to various industries, including:

  • Information Technology (IT)

  • Telecommunications

  • Medical Devices

  • Industrial Automation

  • Consumer Electronics

    • Risk Factors and Safety Implications

    Failure to comply with CISPR 22 can result in safety risks, such as electromagnetic interference causing equipment malfunction or even fire hazards.

    Quality Assurance and Quality Control Aspects

    Eurolabs quality management system (QMS) ensures that all testing services meet the highest standards of accuracy, reliability, and consistency. Our QMS is accredited to ISO/IEC 17025:2005 by a recognized accreditation body.

    Test Conditions and Methodology

    The CISPR 22 test involves measuring the radiated and conducted electromagnetic emissions of IT equipment using specialized equipment and techniques. The test conditions include:

  • Frequency range: 150 kHz to 1000 MHz

  • Test equipment: Emission measurement apparatus, such as a spectrum analyzer or signal generator

  • Test environment: Controlled laboratory space with specified temperature, humidity, and pressure levels

    • Test Reporting and Documentation

    Eurolabs test reports are comprehensive and include detailed information on the testing parameters, conditions, and results. Our reporting standards conform to those specified by international standards organizations.

    Why This Test Should Be Performed

    The benefits of performing CISPR 22 radiated and conducted emission tests for IT equipment include:

  • Ensuring compliance with regulatory requirements

  • Minimizing electromagnetic interference risks

  • Enhancing product reliability and performance

  • Reducing costs associated with non-compliance

  • Improving customer satisfaction and loyalty

    • Why Eurolab Should Provide This Service

    Eurolab is a trusted provider of laboratory testing services, offering:

  • Expertise in CISPR 22 testing and related standards

  • State-of-the-art equipment and facilities

  • Qualified and certified personnel

  • Accreditation and certification details

  • International recognition and partnerships

    • Test Conditions and Methodology (Detailed)

    1. Preparation: The test sample is prepared according to the relevant standard, ensuring that it is representative of the production unit.

    2. Measurement Apparatus: Specialized equipment, such as a spectrum analyzer or signal generator, is used to measure the electromagnetic emissions.

    3. Test Environment: The testing environment is controlled to ensure specified temperature (20-30C), humidity (50-70), and pressure levels.

    4. Testing Parameters: The test parameters include frequency range (150 kHz to 1000 MHz), emission level limits, and measurement accuracy.

    5. Data Collection: Data is collected using specialized software and equipment, ensuring accurate and reliable results.

    Conclusion

    The CISPR 22 radiated and conducted emission testing for IT equipment is essential for ensuring compliance with regulatory requirements and minimizing electromagnetic interference risks. Eurolabs laboratory testing services provide expert assistance in meeting these standards, ensuring that your products are safe, reliable, and compliant with international regulations.
